SAMSUNG Series 3 59cm 4-Zone Touch Induction Hob NZ64F3NM1AB
Images are for reference; the actual product may differ in color or appearance. Please refer to the SKU and manufacturer details for exact specifications.
Model: NZ64F3NM1AB/UR (Series 3)
Type / Form Factor: Built-In Electric Induction Hob / Cooktop
Surface Material: Sleek, high-durability Black Glass-Ceramic
Frame Aesthetic: Modern Cut Edge (Frameless design)
Burner / Zone Configuration: 4 Independent Round Induction Cooking Zones
Power / Output Levels: 9 standard power increments per zone, plus an intensive Power Boost modifier
Power Boost Function: Direct high-speed heat boost available on all 4 modules simultaneously for up to 10 minutes to rapidly boil water or sear meat
Cooking Zone Modules & Wattages:
Left Front (Small): 140 mm diameter — 1250W (Boost up to 1500W)
Left Rear (Large): 220 mm diameter — 2350W (Boost up to 2600W)
Right Front (Large): 220 mm diameter — 2350W (Boost up to 2600W)
Right Rear (Small): 140 mm diameter — 1250W (Boost up to 1500W)
Total Connected Electrical Load: 7.2 kW Maximum Rated Power (Requires dedicated hardwired 32-Amp electrical connection)
Control Panel Layout: Centered front-mounted Smart Touch Control keys with a responsive Red LED numerical display
Core Safety Operations:
H-Shape Residual Heat Indicator: A clear digital safety tracker displaying a capital "H" when a zone is too hot to touch, changing to a lowercase "h" as it cools.
Auto Pan Detection: Intelligent built-in sensors verify that suitable inductive magnetic cookware covers at least 60% of the active zone, sending alerts if matching fails.
Safety Shutoff Modality: Automatically shuts down specific cooking zones if the settings remain unchanged for a long duration or are left unattended.
Digital Child Safety Lock: Disables the touch panel entirely to prevent accidental or unauthorized cooking surface activation.
Additional Systems: Integrated Kitchen Countdown Timer and Quick Stop button functionality.
Device Dimensions (WxHxD): 590 x 57 x 520 mm
Required Worktop Cutout Size (WxD): 560 x 490 mm
Product Weight: 10.5 kg Net weight | 12.0 kg Gross Box weight
Box Package Dimensions (WxHxD): 690 x 115 x 645 mm
Power Source: AC 220-240 V, 50 / 60 Hz
